SEKO WareDose 35 Digital Dosing System – conductive probe, Wi-Fi – dry detergent (solenoid valve) + rinse

Rugged dual-pump dosing system for heavy-duty dishwashers (50+ h/week).

The WareDose 35 is a compact two-pump chemical dosing system built for heavy-duty commercial dishwashing and glasswashing operations running beyond 50 hours a week. A microcontroller manages dosing, and a conductivity probe (inductive on request) detects and holds the detergent concentration steady in the wash tank.

High-volume dishwashing lines need dosing that keeps up with the pace without drifting out of range or demanding constant adjustment. The WareDose 35 accepts up to three input signals from the dishwasher (first-fill solenoid, rinse solenoid and wash pump, 12 to 230 VAC), and separate level control inputs for each pump flag a low chemical before it becomes a problem. Dosing can be set to probe, probeless or simplified mode to suit different field conditions.

The system is now also available with a connection to the SekoWeb online platform and mobile app, and an optional built-in Wi-Fi module allows remote monitoring. Dose counters make it possible to check wash performance and consumption statistics over time, and a Vacuum Switch option extends level control to bag-in-box chemicals.

• Dual-pump dosing designed for use beyond 50 hours a week
• Conductivity probe (inductive available on request) that holds the detergent concentration steady
• IP65 protection and Class II electrical insulation
• Separate level control inputs for both pumps
• Accepts up to 3 input signals from the dishwasher (first fill, rinse, wash pump), 12 to 230 VAC
• Dosing modes: probe, probeless or simplified (patented)
• Dose counters for wash performance and consumption statistics
• Optional built-in Wi-Fi module and SekoWeb / mobile app connectivity for remote monitoring

Applications: Hood or flight-type dishwashers, Conveyor or tunnel dishwashers, High-volume dishwashing operations
